standards
IEC62368-1, IEC60335-1, Dekra BS EN/EN60335-1,BS EN/EN62368-1,UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved
Technische Daten
Technical data
| field of application | industrial |
| design | module |
| operating mode | ac/dc |
| power | 90 W |
| input voltage 1 | 80 Vac – 305 Vac |
| input voltage 2 | 113 Vdc – 431 Vdc |
| output voltage | 12 Vdc | 15 Vdc | 24 Vdc | 48 Vdc |
| operating temperature | -30 °C ... +80 °C |
| numbers of output | 1 |
| manufacturer | Mean Well |
